PRODUCTS
BodyShell Mounting Systems
Zero Clips, Zero Drag, Zero Hassle
Description
Mount in seconds race for hours with this revolution in Bodyshell mounting.
Ever since the earliest days of RC cars, metal body clips have been a presence on the outside of every bodyshell. This no longer needs to be the case
Designed and developed by Mark Dieterman. This innovative system has been extensively tested. You will never want to go back to traditional clips!
Available now to suit the Schumacher Eclipse, with upcoming versions inculding Awesomatix A12X
Specification
- Weight: +6g
- Car/Shell: Schumacher E5 / Montech M20/MT-21
Documents
Ultra Low ESR capacitor
The 1S Ultra Low ESR Power Capacitor minimises power losses to give greater performance!
Description
As used by Andy Murray to win the IFMAR 2020 1/12th Stock World Championship. Also installed in the winning cars at the European Championships and at UK National level.
The RC Dynamics 1S Super Low ESR Power capacitor, is manufactured using the highest performance components available and is tailored to suit RC models powered by a 1S Lipo Voltage source.
Can be used in Stock and Modified classes.
Available from
Schumacher Racing
Technical Information
The primary purpose of the ESC power capacitor is to minimise power losses caused by the high frequency switching currents generated during motor commutation/control. The goal being to maximise ESC performance and minimise the heat generated in the internal circuits. It is very important that the ESC has a power source with minimal source impedance.
The latest LiPo batteries used in 1S on road racing now already provide an incredibly low internal resistance. Therefore in order for the capacitor to provide maximum benefit it must have an ESR (Effective Series Resistance) at the relevant frequencies, at least an order of magnitude less than the LiPo battery internal resistance. The traditional Aluminium Electrolytic power caps do not have such a low ESR.
Specification
- Maximum Operating Voltage: 1S LiPo only
- Capacitance: 800uF
- Effective Series Resistance: Ultra Low < 0.2mΩ
- Weight: 7g
- Dimensions: 27mmx8mmx7.5mm
- Input wires: Flexible Silicone 18AWG
RC Dynamics 1S Voltage Booster
The orginal and best 1S Booster - Proven at the highest level for over 15years
Description
The RC Dynamics Voltage Booster was designed in 2009 for use in both 1S LiPo and 4 cell NiMH powered 1/12 racing.
If the main battery pack does not have sufficient voltage to power the electronics, the voltage booster ensures that
electronics are supplied with a stable 6V supply throughout the duration of the run, regardless of input voltage.
Minature, low weight design with inbuilt switch
Extensive racing success at national, european and world level for 15years
Even with many ESCs now featuring internal voltage booster circuitry,
the orignial RC Dynamics Voltage Booster is still the go to option to ensure reliable elctronics in harsh conditions like open modified 1/12 competition.
Technical Information
Output overcurrent/short circuit protection prevents damage to the booster circuitry in the event of a fault with the connected electronics. LED Status indicator- Provides quick and easy indication that the booster is powered and the switch is in the on position
Specification
- Input Voltage: 1S LiPo only
- Output Voltage: 6.0V
- Quiescent Current: 5mA
- Maximum Current: 1.5A
- Dimensions including heatshrink: 17mmx23mm
- Weight: approx 6g
- Input Wires: 130mm 22AWG Aircraft Spec
- Output Wires: 90mm 24AWG Flexible Silicone
High Power 1S Voltage Booster
& Integrated Low ESR capacitor
The New Generation
Description
Details to follow
Specification
Specification details to follow
